When large amounts of scrap metal, waste, rocks, logs, or other loose materials need to be loaded and moved, an ordinary excavator bucket may not be the most efficient choice. This is where an orange peel grapple can make a major difference. Designed with multiple curved jaws that open and close around materials, this attachment can pick up irregular, bulky, and loose loads efficiently. It is widely used with excavators, cranes, and other material-handling equipment. For recycling companies, scrap yards, demolition contractors, ports, waste-treatment facilities, and construction companies, the right grapple can help improve loading efficiency while reducing manual handling. For more information, please contact YG anytime.
Want to Know More Detailed Product Information? Contact YG Now!
YG Orange Peel Grapple Parameter
| Item/Model | Unit | YGO04A | YGO06A | YGO08A | YGO06B | YGO08B |
| No. of Jaw | piece | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 |
| Suitable Excavator | ton | 6-9 | 10-17 | 18-25 | 10-17 | 18-25 |
| Weight | kg | 355/420 | 900/1000 | 1650/1900 | 850/1000 | 1700/1950 |
| Max Open Jaw | mm | 1200 | 1600 | 2050 | 1900 | 2500 |
| Height of Opened Grapple | mm | 1000 | 1500 | 1700 | 1550 | 2000 |
| Working Pressure | bar | 200 | 260 | 320 | 260 | 320 |
| Working Flow | lpm | 50-100 | 60-120 | 200-250 | 60-120 | 200-250 |
| Capacity | m3 | 0.3 | 0.4 | 0.8 | 0.5 | 1 |
Want to Know More Detailed Product Information? Contact YG Now!
What Does an Orange Peel Grapple Actually Do?
The main job of an orange peel grapple is simple: Grab → Lift → Move → Release
But this simple process can solve many material-handling problems.
- Grab Irregular Materials. Scrap metal and demolition waste rarely have regular shapes. The multiple jaws can surround irregular objects from different directions.
- Load Loose Materials. When materials are scattered across a work area, the grapple can gather them and load them into trucks or containers.
- Handle Heavy Materials. The hydraulic structure provides strong gripping force, making it suitable for demanding material-handling applications.
- Sort Different Materials. Operators can use the attachment to move selected materials from one location to another. This is particularly useful in recycling yards and demolition projects.
- Reduce Manual Handling. Workers do not need to manually move large or heavy pieces of material. The excavator handles the main lifting operation.
- Improve Loading Efficiency. Instead of repeatedly using a bucket to push and scoop materials, the operator can directly grab them. This can make certain loading operations faster and easier.
Want to Know More Detailed Product Information? Contact YG Now!
Where Is an Orange Peel Grapple Used? 8 Applications
One of the biggest advantages of an orange peel grapple is its versatility. Here are some common applications.
- Scrap Metal Recycling. Scrap yards are one of the most common applications. Operators can use the grapple to pick up steel plates, pipes, metal frames, scrap machinery, automobile parts, and steel structures. The jaws can surround irregular scrap materials and move them to sorting or processing areas.
- Demolition Projects. After a building is demolished, large amounts of mixed materials can remain on the site. The grapple can help collect and load metal and other suitable materials. It can also help separate recyclable materials from general construction waste.
- Waste Treatment Facilities. Waste-processing facilities often need to move large quantities of bulky material. A grapple can help operators load waste into trucks, hoppers, containers, sorting systems, and processing equipment. This reduces the need for manual handling.
- Ports and Terminals. Ports often handle bulk materials such as scrap metal, industrial waste, and other loose cargo. A suitable grapple can help load and unload materials efficiently. The ability to open widely and grip large loads makes it useful for certain bulk-handling operations.
- Construction Sites. Construction projects generate many types of waste. An excavator equipped with a grapple can collect steel bars, metal pipes, wooden materials, construction debris, and large fragments. This can help keep the site cleaner and improve material recovery.
- Quarry and Stone Handling. Depending on the grapple configuration and material size, it can also be used for handling rocks and irregular stone materials. The operator can grab individual pieces and move them to another location.
- Timber and Log Handling. Some grapple configurations can be used to handle logs and timber. The curved jaws can surround cylindrical materials and hold them during transportation. The specific grapple design should always be selected according to the material type and required load capacity.
- Industrial Material Handling. Factories and industrial yards often need to move bulky materials between storage, processing, and loading areas. A grapple-equipped excavator can provide a flexible solution without requiring a dedicated material-handling machine for every task.
Want to Know More Detailed Product Information? Contact YG Now!
Fixed vs. Rotating Orange Peel Grapple: Which One Is Better?
| Comparison | Fixed Orange Peel Grapple | Rotating Orange Peel Grapple |
|---|---|---|
| Basic Structure | Simple structure without a dedicated rotation mechanism | Equipped with a hydraulic or mechanical rotation system |
| Grapple Movement | Moves mainly with the excavator arm | Can move with the excavator arm and rotate independently |
| Material Positioning | Suitable for basic grabbing and loading | Easier to adjust the position and direction of materials |
| Operation Difficulty | Simple and easy to operate | Requires slightly more operating experience |
| Loading Efficiency | High for straightforward loading tasks | Higher flexibility for complex loading and sorting tasks |
| Scrap Metal Handling | Suitable for regular scrap loading | Excellent for irregular scrap and selective material handling |
| Demolition Waste | Good for collecting and loading debris | Better when materials need to be repositioned or sorted |
| Container Loading | Suitable for simple loading | More convenient for arranging materials inside containers |
| Material Sorting | Basic sorting capability | Better control for selecting and sorting different materials |
| Curved/Confined Working Areas | Relatively limited flexibility | Better flexibility in confined or complex areas |
| Material Orientation | Depends mainly on excavator movement | Can rotate materials to the desired direction |
| Maintenance | Simple maintenance and fewer moving parts | More components require regular inspection and maintenance |
| Weight | Generally lighter | Generally heavier because of the rotation mechanism |
| Cost | Usually more economical | Usually higher due to the additional rotation system |
| Best For | Simple, repetitive grabbing and loading | Flexible grabbing, sorting, positioning, and complex handling |
| Recommended Users | Construction contractors, basic scrap yards, material handlers | Recycling centers, demolition companies, ports, industrial yards |
| Main Advantage | Simple, economical, easy to maintain | Flexible, precise, and better material positioning |
Want to Know More Detailed Product Information? Contact YG Now!
Customer Feedback: Scrap Metal Recycling Project
“We use the excavator orange peel grapple in our scrap metal recycling yard. Before purchasing it, loading irregular steel pieces with a bucket was slow because the material often slipped or had to be repositioned several times. The grapple changed our workflow. The multiple jaws can surround different shapes of scrap and hold them securely during lifting. Our operator also finds sorting easier because he can pick selected pieces instead of moving the whole pile. After several weeks of use, we noticed that our daily loading efficiency improved significantly, especially during busy truck-loading periods. For our recycling business, the grapple has become a very practical material-handling tool.”
Customer Feedback: Demolition Project
“Our company purchased an orange peel grapple for a demolition project where we had to handle a large amount of steel and mixed construction debris. The biggest benefit was flexibility. The operator could grab individual steel sections and move them directly to the collection area. Compared with using a standard bucket, there was less pushing and repositioning. We also liked the control provided by the multiple jaws. It was easier to pick up long and irregular pieces without constantly adjusting the excavator. The attachment helped us keep the work area more organized and reduced unnecessary manual handling. It is now one of the attachments we consider for future demolition projects.”
Overseas Customer Feedback: Port Material Handling
“We use our orange peel grapple in a material-handling operation near a port. Our work involves moving scrap and bulky industrial materials between storage areas and trucks. The rotating design was particularly useful because the operator could change the material direction before loading. This saved time when the material needed to be positioned inside a limited space. We were initially concerned that the operator would need a long time to learn the attachment, but the controls were easy to understand. After the operator became familiar with the grapple, the loading process became smoother. We are satisfied with its flexibility and believe it is a good fit for our daily handling work.”
Want To Quickly Launch A New Project? Contact YG For Customized Services
An orange peel grapple is a practical solution for companies that regularly handle scrap metal, demolition materials, waste, timber, stones, or other irregular loads. Its biggest advantage is its gripping method.
For recycling yards, demolition contractors, ports, waste-treatment facilities, construction sites, and industrial material-handling projects, choosing the right orange peel grapple can turn an ordinary excavator into a more flexible and productive material-handling machine.
If you are looking for an orange peel grab for sale, send YG your excavator model, tonnage, hydraulic flow, hydraulic pressure, and the material you need to handle. We can help you select a suitable grapple configuration for your project.
