A hydraulic core drilling rig is a professional drilling machine that uses a hydraulic system to control drilling operations. Unlike traditional mechanical drilling equipment, it uses hydraulic pressure to drive key components such as the drilling head, feeding system, and rotating mechanism. This design provides stronger power output, smoother operation, and better adaptability in complex working environments. The hydraulic coring machine is mainly used for obtaining underground rock samples. These samples help engineers and geologists analyze rock structures, mineral resources, underground conditions, and construction environments. Want to know more information? Contact YG now.
Want to Know More Detailed Product Information? Contact YG Now!
YG Hydraulic Core Drilling Rig Parameters
| Model | YGX-400 | YGX-600 | YGX-800 | YGX-1000 |
| Drilling Depth(M) | 180-400-500 | 200-600-650 | 400-800-1000 | 500-1000-1100 |
| Rated pressure(MPA) | 21 | 21 | 25 | 28 |
| Rated Flow(L/min) | 168 | 192 | 260 | 300 |
| Heat Dissipation Mode | Air cooling+water cooling | |||
| Engine Brand | Yuchai | Yuchai | Yuchai | Cummins |
| Rated power/speed | 78kW/ 2400r/min | 92kW/ 2400r/min | 92kW/ 2400r/min | 154kW/2400r/min |
| Drilling Angle(°) | 0-90 | 45-90 | 45-90 | 45-90 |
| Lifting Force(T) | 12 | 16 | 24 | 30 |
| Feed Force(T) | 6 | 8 | 12 | 15 |
| Hydraulic Mud pump flow | 30-90（L/min） | 30-90（L/min） | 90-180（L/min） | 90-180（L/min） |
| Hydraulic Mud pump power | 4-7(MPA) | 4-7(MPA) | 4-7(MPA) | 4-7(MPA) |
| Dimension | 4000*1900*1800mm | 4000*2000*1800mm | 5500*2100*2000mm | 6000*2200*2400mm |
| Weight | 4.3T | 4.5/5.5T | 6.5T | 7.5T |
Want to Know More Detailed Product Information? Contact YG Now!
I. How Does a Hydraulic Core Drilling Rig Work? 5 Steps
- Machine Installation and Site Preparation. Before drilling begins, the operator prepares the drilling site. The ground must be checked to ensure stability and safety.
- Starting the Hydraulic Power System. After installation, the hydraulic system is activated. The hydraulic pump generates pressure and transfers hydraulic energy to different parts of the machine, including: Hydraulic motor, Rotation system, Feeding system, and lifting mechanism. This allows the drilling rig to operate smoothly with powerful force.
- Drill Rod Rotation and Rock Cutting. During drilling, the hydraulic motor drives the drill rod to rotate. The drill bit at the bottom of the rod cuts into the rock formation. The rotation speed and pressure can be adjusted according to the hardness of the rock.
- Core Sample Collection. When the drill bit penetrates the ground, the core barrel captures a cylindrical rock sample. These samples are removed and analyzed by engineers or geologists.
- Removing Core Samples and Continuing Drilling. After the core barrel is full, operators remove it from the drilling hole and take out the sample. The drilling process continues until the required depth is reached.
Want more details? Please click https://ygmachtech.com/how-does-a-fully-hydraulic-core-drilling-rig-work/
Want to Know More Detailed Product Information? Contact YG Now!
II. Why Should You Buy a Hydraulic Core Drilling Rig? 5 Practical Benefits for Your Business
Investing in a hydraulic coring machine can bring many advantages to drilling companies, mining businesses, and engineering contractors.
1. Higher Work Efficiency
One of the biggest benefits of hydraulic drilling equipment is improved productivity.
The hydraulic system provides strong and continuous power, allowing the machine to complete drilling tasks faster.
Compared with manual or traditional drilling methods, a hydraulic rig can:
- Reduce drilling time
- Increase daily production
- Handle deeper drilling projects
2. Better Performance in Difficult Conditions
Construction and exploration projects often face complicated environments, including mountains, rocky areas, and uneven terrain. A full hydraulic core drilling rig can adapt to different conditions because of its flexible hydraulic control.
It can work effectively in:
- Hard rock areas
- Remote locations
- Mining sites
- Underground projects
3. Lower Labor Costs
Traditional drilling operations often require more workers to control and adjust equipment. Hydraulic drilling machines simplify operation through automatic hydraulic control systems.
This means:
- Fewer operators are needed
- Less physical labor is required
- Training time is reduced
4. More Accurate Geological Data
For exploration projects, accurate samples are extremely important. A high-quality hydraulic core drilling rig provides clean and complete core samples, helping professionals make better decisions about mining resources and construction plans.
5. Long Service Life and Good Investment Value
A durable hydraulic drilling machine can work for many years with proper maintenance.
Although the initial investment may be higher than some traditional equipment, the long-term benefits include:
- Lower maintenance costs
- Higher productivity
- Better project results
For companies looking for reliable equipment, choosing a hydraulic core drilling rig for sale can be a smart business decision.
Want to Know More Detailed Product Information? Contact YG Now!
III. Why Global Buyers Choose YG Hydraulic Drilling Equipment? 3 Real Customer Feedback
Many international customers have shared positive experiences after purchasing hydraulic drilling machines.
Customer Feedback from Mining Companies
Mining companies often mention that hydraulic drilling rigs provide strong drilling performance in challenging rock formations.
A customer from Africa said:
“The hydraulic core drilling rig works very smoothly. It has enough power for our mineral exploration projects and helps us save a lot of working time.”
Customer Feedback from Geological Survey Teams
Geological exploration teams appreciate the accuracy and stability of hydraulic coring equipment.
A customer from South America commented:
“The machine is easy to operate, and the core samples are very complete. It improves our exploration efficiency significantly.”
Customer Feedback from Construction Contractors
Construction companies use hydraulic drilling rigs for foundation investigations and engineering projects.
A customer from Southeast Asia reported:
“The equipment performs well even in complicated terrain. The hydraulic system makes operation much easier for our workers.”
Want More Case Studies? Contact YG For Customized Services.
IV. 4 FAQs About YG Hydraulic Core Drilling Rig
A: A hydraulic core drilling rig is mainly used for geological exploration, mining exploration, rock sampling, engineering surveys, and foundation investigation. It collects underground core samples for analysis.
A: Yes. Modern full hydraulic drilling rigs are designed with simple control systems. Operators can adjust drilling speed, pressure, and rotation parameters easily after basic training.
A: Yes. A powerful full hydraulic core drilling rig is designed to handle different geological conditions, including hard rock formations. The hydraulic system provides strong torque and stable drilling force.
A: Required drilling depth, rock conditions, machine power, manufacturer experience, after-sales service, etc. But if you don’t know, you can contact YG directly.
A: A core drill rig can be used for both core sampling and water well drilling, while a fully hydraulic core drill rig can only be used for core sampling.
Want a more complete sample? Choose YG Hydraulic Core Drilling Rig
A full hydraulic core drilling rig is an advanced solution for modern drilling projects. With strong hydraulic power, accurate control, high efficiency, and excellent adaptability, it has become an important tool in mining, geology, and construction industries. Whether you need a hydraulic core drilling rig, a hydraulic coring machine, or are looking for a reliable hydraulic core drilling rig for sale, choosing YG Machinery’s high-quality equipment can help your business achieve faster drilling, better sample quality, and lower operating costs. Don’t hesitate to contact YG today!
